MFJ 8621

VHF Data Radio


Omschrijving
Excl btw
Incl btw
Per
Aantal

MFJ 8621
Art. 808765
Excl btw € 123,97
Incl btw € 150,00
Per 1 St.
Alle prijzen zijn excl. verzendkosten

MFJ 8621 compacte packet VHF transceiver

MFJ Packet Only Transceiver. Runs all data rates from 1200 to 9600 Baud. MFJ 8621 is compatible with all TNCS's having hardware DCDs.

Receiver
Frequency Coverage : 144-148 MHz
Sensitivity : 0.6 µV for 12 dB Quieting
Image Rejection :  -45 dB or better
1st IF : 10.7 MHz
2nd IF : 455 KHz
1st LO : Crystal , 3rd overtone
2nd LO : 10.245 MHz
Selectivity :  -6 dB at 20 KHz (data-passband filter)
AFSK Output : Unsquelched, 0dBm @ 3.0-KHz deviation
Current Drain : 25 mA

Transmitter
Frequency Control : Crystal, 18-MHz x 8
FSK/AFSK Input level : 150mV p-p @ 1200 baud, .8 V p-p @ 9600
Deviation : 0-5 KHz, adjustable at TNC
RF Power Output : 4.0 - 5.0 Watts into 50 Ohms
VSWR Tolerance : 3:1 Max.
Current Drain : 1.0 Amp @ 13.8 Volts
